Default spring rates:
441/441+: 8k/6k (8k/5k if true rear coilover)
441/441+ Drift Spec: 12k/6k (12k/5k if true rear coilover)
Ride height Options:
Standard: For customers with a 27" or larger rear tire diameter or those who are not seeking a "flush" rear ride height and prefer as much shock stroke as possible.
"Super Low": Recommended for vehicles with a 27" or smaller rear tire diameter who require minimum fender gap. Please note this does not affect the front suspension but does include a shorter rear shock to attain a lower overall ride height.
**For true rear coilover option we recommend reinforcing rear shock mounts with Maximum Motorsports part#MMSM-2 lower shock mounts
Feal Drift and Race Camber Caster Mounts: Full description SN95 Drift and Race Camber Caster Plates
Each shock is designed with expertise from our success in many top-level international motorsports and through years of experience tuning various shock brands. We at Feal Suspension strongly believe that our coilovers have an edge on shock design that gives you confidence and a competitive advantage where needed most.
441 - Damping adjustability that adjusts Rebound and Compression in one knob. Very easy to tune vehicle firmness, dive, and roll.
441.5 - 1 Way Adjustable fronts, 2 way adjustable rears with remote reservoirs. The 441.5 kit is a great “bang-for-the-buck” solution for Drifting and Drag Racing. Fine tune traction at every track by adjusting the rear compression force. Also, the rear shock’s 442 remote reservoir has tons of compression force adjustably! Dial forward bite, side bite, squat, and bottoming resistance for any track condition. Over the years we have built many of these requested custom kits for budget driven teams. Many podiums later, we created a part number so you too can have this kit.
442 - 2 Way Adjustable fronts and rears with remote reservoirs. Separate damping adjustability for Rebound and Compression. Rebound adjustability does not change compression force so that you can fine tune the roll and rate of weight transfer. The huge range of compression adjustability is independent of rebound force. The compression adjustability will allow you to adjust for more or less traction and more or less suspension movement on the compression stroke.
443 - 3 Way Adjustable fronts and rears with remote reservoirs. All of the above plus separate damping adjustability for High Speed Compression, Low Speed Compression, and Rebound. Low speed compression damping adjustability allows you to fine tune chassis movement on the compression stroke over round bumps and/or throttle and braking inputs. High speed compression adjustability allows you to fine tune bottoming resistance and wheel movement on the compression stroke over rumble strips and square edge bumps.
Please Note:
For 441.5, 442 and 443 applications the following line lengths -
Macpherson: 10" line, reservoir to be mounted to coilover
Multi-Link: 24" line, reservoir to be mounted remotely
Longer line lengths are available on request for a $30 per corner fee in most applications
*images may not reflect actual product
